Single Shaft Shredder
    Publish time 2021-12-31 08:23

Single Shaft Shredders are small to medium size reduction machines suitable for processing a wide range of materials to a uniform particle size. The products can often be sold as is, or be sent for further processing through additional equipment. Through outputs typically range between300kg/hr –5,000kg/hr+ depending on the model.

Single Shaft Shredder

Single Shaft Shredder


Single Shaft Shredders are small to medium size reduction machines suitable for processing a wide range of materials to a uniform particle size. The products can often be sold as is, or be sent for further processing through additional equipment. Through outputs typically range between300kg/hr –5,000kg/hr+ depending on the model.


Material type and application as below:

1. Plastics –Moulding, Purging/Lump, Profiles, Films etc.

2. Timber/Wood – Pallets, Joiners Waste, Green Waste etc.

3. Paper & Cardboard – Confidential Documents, Production Waste, Packaging Materials etc.

4. Copper Cable – Household, Telecoms and Industrial Cables including S.W.A

5. Aluminum – Used Beverage Cans (UBC’s), Swarf, Cables etc.

6. Textiles – Carpet (Rolls & Tiles), Garments etc.

7. Security Destruction – Counterfeit Items, Faulty Goods, Out of Date Stock etc.

8. Foam – Production Waste etc.


Technical Information

Model No.

WL-S600

WL-S800

WL-S1000

WL-S1200

WL-S1500

Hopper Size

800x600mm

1300x800mm

1300x1000mm

1300x1200mm

1300x1500mm

Discharge Height

490mm

565mm

565mm

565mm

565mm

Ram stroke

500mm

815mm

815mm

815mm

815mm

Rotating Dia.

Φ220mm

Φ400mm

Φ400mm

Φ400mm

Φ400mm

Rotor Operation Length

600mm

800mm

1000mm

1200mm

1500mm

Rotor Speed

80rpm

80rpm

80rpm

80rpm

80rpm

Screen

Φ20/40mm

Φ40mm

Φ20mm

Φ30mm

Φ20mm

Movable knife

23pcs

35pcs

45pcs

55pcs

70pcs

Fixed Knife

4pcs

4pcs

4pcs

6pcs

6pcs

Driven Power

18.5kw

37kw

45kw

55kw

75kw

Hydraulic Power

3.75kw

3.75kw

3.75kw

5.5kw

5.5kw
